Chauvin Arnoux CA6424 Earth Tester

$ 98.49

DescriptionChauvin Arnoux CA6424 Earth TesterProduct Details:The Chauvin Arnoux CA6424 Earth Tester is the ideal instrument for 2P and 3P earth measurements to be taken safely and easily. Both text markings and colour coding help the users to avoid connection errors. Users are able to measure voltage up to 600V with all measurements and functionality are directly accessible on the front panel which can be used even with gloves on.With automatic start up in 2P earth measurement mode, the CA6424 instantly allows the user to test the integrity of the H stake. When using the 3P earth mode, the CA6424 memorises the 52%, 62% and 72% measurement values and calculates the differences in % relation to the average. If the difference is too large , the percentage value is displayed on screen with a flashing display.Users are able to use the CA6424 to measure line (phase) current and leakage current from 0.5mA to 60A thanks to the special connection technology for the G72 clamp (optional). The CA6424 has a dedicated key for cable compensation, whilst the LED screen indicates when a hazardous voltage is detected, with a NOISE symbol flashing should noise voltage be present. If a noise filled environment is detected, the CA6424 automatic switching from a frequency of 128Hz to 256Hz will help improve the measurement accuracy.The CA6424 boasts a 3 display backlit screen with users able to view useful measurements on a single screen, any errors detected in measurements or recorded values as well as complementary information such as USE and HR.The CA6424 complies with IEC 61557-1 and IEC 61557-4 and is 600V CAT IV rated. The unit is IP65 rated offing protection from dust and low pressure water jets from any direction and has been drop tested to 1 metre as per IEC 61010-1 .Powered by 6 rechargeable batteries, the CA6424 has a battery life for up to 1500 measurements 3P earth measurements at 10Ω with an automatic power off function that can be deactivated further preserving battery life.CA6422 and CA6424 Comparison chartCA6422CA6424Voltage measurement✔2P Resistance measurement✔✔3P Earth resistance measurement✔✔Mean of the earth measurement at 52%, 62% and 72%✔RH stake resistance measurement✔USE voltage measurement✔Detection of spurious voltage of USE✔✔Measurement of AC current with optional G72 clamp✔Measurement ModeR 2P (Ω), R 3P (Ω)V, I, R 2P (Ω), R 3P (Ω)Auto power off function✔Power supply6 x LR 6 or AA batteries6 x NiMH rechargeable batteries, charging time approx.. 6 hrsBattery life> 2,000 x 3P earth measurements at 100 Ω> 1,500 x 3P earth measurements at 100 ΩKey Features:Voltage detection from 0 to 600V2P resistance: 0.05 Ω to 50 kΩ3P earth: 0.5 Ω to 50 kΩMeasurement modes: one-shot or permanentRH stake resistance measurementUSE voltage measurementCurrent measurement with the G72 clamp: 0.5 mA to 60 AAutomatic power-off function that can be deactivatedComplies with IEC 61557-1 and IEC 61557-4IP65 rated600V CAT IV ratedNiMH batteries that are rechargeable via the mains, USB socket or vehicle cigarette lighter1 metre drop tested as per IEC 61010-1What’s In The Box?Chauvin Arnoux CA6424 Earth Tester1 carrying bag6 NiMH batteries1 USB 2A power supply1 USB micro-razor power cable1 multilingual quick start guide,1 safety datasheet1 battery datasheettest report with measurement resultsWEB link/QR Code for downloading the manuals
